Top 40 MCQs On Units & Measurements For KVS NVS EMRS PGT Physics Mains 2026 With Solutions

Q: What is a parsec and what does it measure?

A parsec is a unit of distance (not time) equal to approximately 3.086 × 10^16 metres or about 3.26 light-years. It stands for Parallax Second — the distance at which 1 AU subtends an angle of 1 arc-second. Despite the '-sec' suffix, it measures distance, not time.

Q: How do you calculate percentage error in a derived quantity like P = a³b²/cd?

Multiply each quantity's percentage error by its power in the formula, then add all terms. For P = a³b²/cd: % error = 3(%a) + 2(%b) + 1(%c) + 1(%d). Errors always add — never subtract. Powers in numerator and denominator both contribute positively.

Q: How many significant figures does 0.0003 have?

0.0003 has only 1 significant figure. Leading zeros are never counted as significant — they only indicate decimal position. Only the digit 3 is significant.

Q: What are the dimensions of Gravitational constant G?

From F = GM₁M₂/r², G = Fr²/M² = [M⁻¹L³T⁻²]. This is derived by substituting dimensions of Force (MLT⁻²), length squared (L²), and mass squared (M²).

Q: What does 1/√(μ₀ε₀) represent and what are its dimensions?

1/√(μ₀ε₀) equals the speed of light c in vacuum (≈ 3×10⁸ m/s). Its dimensions are [LT⁻¹]. This is a fundamental result from Maxwell's electromagnetic equations.

Q: What is the percentage error formula for density of a cylindrical wire?

For density ρ = M/(πr²L): % error in ρ = %ΔM + 2×(%Δr) + %ΔL. The radius error is always doubled because r is squared in the formula. Constants like π contribute zero error.

5/5 - (4 votes)

Welcome to your ultimate revision guide for the KVS, NVS, and EMRS PGT Physics Mains 2026. The “Units & Measurements” chapter is highly scoring if you know the right tricks. Below are the Top 40 MCQs extracted from premium study material, complete with unique, easy-to-understand solutions and special Cheat Points to save you crucial seconds in the exam hall.

📋 Table of Contents

Part 1 — Units and Basic Concepts (Q1–Q3)
Part 2 — Significant Figures & Error Analysis (Q4–Q19)
Part 3 — Dimensional Analysis Masterclass (Q20–Q39)
Part 4 — Experimental Skills & Instruments (Q40)
FAQs — Frequently Searched Questions

Units and Basic Concepts

parsec is the unit of

▼

(a) time(b) distance(c) frequency(d) angular acceleration

✓ Ans: (b)

Solution

A parsec is an astronomical unit used to measure massive distances outside our solar system.

💡 Cheat Point: Don’t let the suffix “-sec” fool you! Parsec stands for Parallax Second, which measures distance, not time.

Given that $y = A \sin \left[ \frac{2\pi}{\lambda} (ct - x) \right]$ , where $y$ and $x$ are measured in metres. Which of the following statements is correct?

▼

(a) the unit of $(ct - x)$

is same as that of $\frac{2\pi}{\lambda}$

(b) the unit of $c$

is same as that of $\frac{2\pi}{\lambda}$

is same as that of $x$

but not of $A$

(d) the unit of $\lambda$

is same as that of $x$

and $A$

✓ Ans: (d)

Solution

The physical quantities $y$

, $x$

, and Amplitude $A$

are all lengths, so they are in meters. The argument inside the sine function must be dimensionless, so $\lambda$

must match the length unit of $x$

💡 Cheat Point: In wave equations, variables representing physical spread (like $y, x, \lambda, A$

) always share the exact same spatial unit!

Match List-I with List-II.

▼

List-I	List-II
A. Surface Tension	I. $kg\ m^{-1} s^{-1}$
B. Pressure	II. $kg\ m\ s^{-1}$
C. Viscosity	III. $kg\ s^{-2}$
D. Impulse	IV. $kg\ m^{-1} s^{-2}$

(a) A-III, B-IV, C-I, D-II(b) A-II, B-I, C-III, D-IV
(c) A-IV, B-III, C-I, D-II(d) A-IV, B-III, C-II, D-I

✓ Ans: (a)

Solution

Surface tension $= F/L = MT^{-2}\ (kg\ s^{-2})$

. Pressure $= F/A = ML^{-1}T^{-2}\ (kg\ m^{-1}s^{-2})$

. Viscosity $= ML^{-1}T^{-1}\ (kg\ m^{-1}s^{-1})$

. Impulse $= MLT^{-1}\ (kg\ ms^{-1})$

💡 Cheat Point: Just match Impulse = Force $\times$

Time ( $kg\ m s^{-1}$

). D matches II. Only option (a) and (c) have D-II. Check Surface Tension next to crack it instantly!

Significant Figures & Error Analysis

The respective number of significant figures for the numbers 23.023, 0.0003 and $2.1 \times 10^{-3}$ are

▼

(a) 4, 4, 2(b) 5, 1, 2(c) 5, 1, 5(d) 5, 5, 2

✓ Ans: (b)

Solution

All non-zero digits and trapped zeros count (23.023 $\rightarrow$

5). Leading zeros never count (0.0003 $\rightarrow$

1). Powers of 10 are ignored ( $2.1 \times 10^{-3} \rightarrow$

2).

💡 Cheat Point: Ignore $10^x$

completely. Only look at the base number!

In an experiment four quantities $a, b, c$ and $d$ are measured with percentage error 1%, 2%, 3% and 4% respectively. Quantity P is calculated as $P = \frac{a^3 b^2}{cd}$ . % error in P is

▼

(a) 10%(b) 7%(c) 4%(d) 14%

✓ Ans: (d)

Solution

Error $= 3(\%a) + 2(\%b) + 1(\%c) + 1(\%d) = 3(1) + 2(2) + 3 + 4 = 14\%$

💡 Cheat Point: Powers jump to the front as multipliers. Divisions turn into additions. Errors always add up; they never subtract!

A physical quantity $y = \frac{a^4 b^2}{(cd^4)^{1/3}}$ has four observables $a, b, c$ and $d$ . The percentage errors are 2%, 3%, 4% and 5%. The error in $y$ will be

▼

(a) 6%(b) 11%(c) 12%(d) 22%

✓ Ans: (d)

Solution

Error $= 4(2\%) + 2(3\%) + \frac{1}{3}(4\%) + \frac{4}{3}(5\%) = 8 + 6 + 1.33 + 6.67 = 22\%$

The density of a cube is measured by measuring its mass and length. If the maximum errors in mass and lengths are 3% and 2% respectively, the maximum error in density would be

▼

(a) 12%(b) 14%(c) 7%(d) 9%

✓ Ans: (d)

Solution

Density $\rho = \frac{M}{L^3}$

. Error $= \%M + 3(\%L) = 3\% + 3(2\%) = 9\%$

The density of a material (cube) is determined. Relative error in measuring mass and length are 1.5% and 1%. Maximum error in density is

▼

(a) 2.5%(b) 3.5%(c) 4.5%(d) 6%

✓ Ans: (c)

Solution

Using $\rho = \frac{M}{L^3}$

, error $= 1.5\% + 3(1\%) = 4.5\%$

A wire has a mass (0.3 ± 0.003) g, radius (0.5 ± 0.005) mm and length (6 ± 0.06) cm. The maximum percentage error in density is

▼

(a) 1(b) 2(c) 3(d) 4

✓ Ans: (d)

Solution

Convert values to percentages: Mass error $= (\frac{0.003}{0.3}) \times 100 = 1\%$

. Radius error $= 1\%$

. Length error $= 1\%$

. Density of a cylinder $\rho = \frac{M}{\pi r^2 L}$

. Total error $= \%M + 2(\%r) + \%L = 1\% + 2(1\%) + 1\% = 4\%$

💡 Cheat Point: For wires, formula is always cylinder ( $\pi r^2 L$

). The radius error is always doubled!

A quantity $X = \frac{A^2 B^{1/2}}{C^{1/3} D^3}$ . Percentage errors in A, B, C, D are 1%, 2%, 3%, 4%. Max error in X is

▼

(a) (3/13)%(b) 16%(c) -10%(d) 10%

✓ Ans: (b)

Solution

Error $= 2(1\%) + \frac{1}{2}(2\%) + \frac{1}{3}(3\%) + 3(4\%) = 2 + 1 + 1 + 12 = 16\%$

In the density measurement of a cube, mass and edge length are (10.00 ± 0.10) kg and (0.10 ± 0.01) m. Error in density is:

▼

(a) $0.10\ kg/m^3$

(b) $0.31\ kg/m^3$

(d) $0.10\ kg/m^3$

*(Note: Source prints options identically; actual calculated absolute error differs in magnitude scale, but base value aligns with 0.31)*

✓ Ans: (b)

Solution

Relative error $\frac{\Delta \rho}{\rho} = \frac{0.10}{10} + 3 \times \frac{0.01}{0.10} = 0.01 + 0.3 = 0.31$

Simple pendulum g-determination: 20 oscillations take 30s (measured with 1s least count watch). Length is 55.0 cm (1 mm least count scale). Percentage error in g is close to:

▼

(a) 0.7%(b) 0.2%(c) 3.5%(d) 6.8%

✓ Ans: (d)

Solution

$g = \frac{4\pi^2 L}{T^2}$

. % error in $g = \%L + 2(\%T)$

. Error in $L = (\frac{0.1}{55.0}) \times 100 \approx 0.18\%$

. Error in $T$

for total time $= (\frac{1}{30}) \times 100 \approx 3.33\%$

. Total $= 0.18 + 2(3.33) \approx 6.8\%$

💡 Cheat Point: Total time error is $\frac{\text{Least Count}}{\text{Total Time}}$

. Don’t divide by the number of oscillations for the percentage!

$Z = \frac{a^2 b^{2/3}}{\sqrt{c} d^3}$ . Percentage errors in a, b, c, d are 2%, 1.5%, 4% and 2.5%. Percentage error in Z is

▼

(a) 12.25%(b) 16.5%(c) 13.5%(d) 14.5%

✓ Ans: (d)

Solution

Error $= 2(2) + \frac{2}{3}(1.5) + \frac{1}{2}(4) + 3(2.5) = 4 + 1 + 2 + 7.5 = 14.5\%$

Taking into account significant figures, what is the value of 9.99 m – 0.0099 m

▼

(a) 9.98 m(b) 9.980 m(c) 9.9 m(d) 9.9801 m

✓ Ans: (a)

Solution

$9.99 - 0.0099 = 9.9801$

m. In addition/subtraction, the result retains the least number of decimal places of the given terms (two decimal places from 9.99). So, round to 9.98 m.

Physical quantity $y = m^2 r^{-4} g^x l^{-3/2}$ . Percentage errors in y, m, r, l and g are 18, 1, 0.5, 4 and p respectively. Find x and p.

▼

(a) 5 and ± 2(b) 4 and ± 3
(c) 8 and ± 2(d) 16/3 and ± 3/2

✓ Ans: (d)

Solution

$18 = 2(1) + 4(0.5) + x(p) + 1.5(4) \Rightarrow 18 = 2 + 2 + xp + 6 \Rightarrow xp = 8$

. Checking options, (16/3) × (3/2) = 8. So (d) is correct.

💡 Cheat Point: Work backwards from the options! Find which product $xp$

equals 8.

Area of rectangular field of length 55.3 m and breadth 25 m after rounding off for correct significant digits is

▼

(a) 1382(b) 1382.5
(c) $14 \times 10^2$

(d) $138 \times 10^1$

✓ Ans: (c)

Solution

Area $= 55.3 \times 25 = 1382.5\ m^2$

. Since ’25’ has only 2 significant figures, the answer must be rounded to 2 significant figures, which gives $1400$

or $14 \times 10^2\ m^2$

If $Z = \frac{A^2 B^3}{C^4}$ , then relative error in Z will be

▼

(a) $\frac{\Delta A}{A} + \frac{\Delta B}{B} + \frac{\Delta C}{C}$

(b) $2\frac{\Delta A}{A} + 3\frac{\Delta B}{B} + 4\frac{\Delta C}{C}$

(d) $\frac{\Delta A}{A} + \frac{\Delta B}{B} - \frac{\Delta C}{C}$

✓ Ans: (b)

Solution

Powers become coefficients and negative powers become positive because maximum relative errors are always added.

A cylindrical wire of mass (0.4 ± 0.01) g has length (8 ± 0.04) cm and radius (6 ± 0.03) mm. Maximum error in density is

▼

(a) 3.5%(b) 1%(c) 4%(d) 5%

✓ Ans: (c)

Solution

Error $= (\frac{0.01}{0.4} \times 100) + 2(\frac{0.03}{6} \times 100) + (\frac{0.04}{8} \times 100) = 2.5\% + 1\% + 0.5\% = 4\%$

A metal wire has mass (0.4 ± 0.002) g, radius (0.3 ± 0.001) mm and length (5 ± 0.02) cm. Maximum percentage error in density is

▼

(a) 1.2%(b) 1.3%(c) 1.6%(d) 1.4%

✓ Ans: (c)

Solution

Error $= (\frac{0.002}{0.4} \times 100) + 2(\frac{0.001}{0.3} \times 100) + (\frac{0.02}{5} \times 100) = 0.5\% + 0.66\% + 0.4\% = 1.6\%$

Dimensional Analysis Masterclass

If force (F), velocity (v) and time (T) are taken as fundamental units, dimensions of mass are

▼

(a) $[F v^{-1} T^{-1}]$

(b) $[F v^{-1} T]$

(d) $[F v T^{-2}]$

✓ Ans: (b)

Solution

Force $= \text{Mass} \times \text{Acceleration} = \frac{M \times v}{T}$

. Rearranging, $M = \frac{F \times T}{v} = [F v^{-1} T]$

💡 Cheat Point: Don’t write full MLT equations for these. Use basic physics formulas (like $F = ma = m(v/t)$

) to isolate the unknown!

If momentum (P), area (A) and time (T) are fundamental, dimensional formula of energy is

▼

(a) $[P A^{-1} T]$

(b) $[P^2 A T]$

(d) $[P A^{1/2} T^{-1}]$

✓ Ans: (d)

Solution

$P = MLT^{-1}$

, $A = L^2 \Rightarrow L = A^{1/2}$

. Energy $E = ML^2T^{-2}$

. Multiply and divide P by L/T logic: $E = P \times \frac{L}{T} = P \times A^{1/2} \times T^{-1}$

If energy (E), velocity (v) and force (F) are fundamental, dimensions of mass will be

▼

(a) $[F v^{-2}]$

(b) $[F v^{-1}]$

(d) $[E v^2]$

✓ Ans: (c)

Solution

Kinetic Energy $E = \frac{1}{2} M v^2$

. Constants vanish in dimensions, so $M = \frac{E}{v^2} = [E v^{-2}]$

💡 Cheat Point: $K.E. = \frac{1}{2}mv^2$

finishes this in 3 seconds!

If E = energy, G = gravitational constant, I = impulse and M = mass, dimensions of $\frac{GIM^2}{E^2}$ are same as

▼

(a) mass(b) length(c) time(d) force

✓ Ans: (c)

Solution

$\frac{[M^{-1}L^3T^{-2}] [MLT^{-1}] [M^2]}{[ML^2T^{-2}]^2} = \frac{M^2L^4T^{-3}}{M^2L^4T^{-4}} = [T]$

In a system where force (F), acceleration (A) and time (T) are fundamental, formula of energy is

▼

(a) $[F A T^2]$

(b) $[F A^2 T]$

(d) $[F A T]$

✓ Ans: (a)

Solution

Energy = Work = Force $\times$

Distance. Distance from kinematics $d = \frac{1}{2}AT^2$

. So, Energy $= F \times AT^2 = [FAT^2]$

Dimensional formula of Gravitational constant is

▼

(a) $[M^{-1} L^2 T^{-2}]$

(b) $[M^{-1} L^{-1} T^{-2}]$

(d) $[M L^3 T^{-2}]$

✓ Ans: (c)

Solution

$F = \frac{GM_1M_2}{r^2} \Rightarrow G = \frac{Fr^2}{M^2} = \frac{MLT^{-2} \times L^2}{M^2} = [M^{-1}L^3T^{-2}]$

Match Column-I with Column-II:

▼

Column-I	Column-II
(A) Torque	(p) $[M^1 L^1 T^{-2} A^{-2}]$
(B) Magnetic Field	(q) $[L^2 A^1]$
(C) Magnetic moment	(r) $[M^1 T^{-2} A^{-1}]$
(D) Permeability	(s) $[M^1 L^2 T^{-2}]$

✓ Ans: (a) A→s ; B→r ; C→q ; D→p

Solution

Torque = Force $\times$

distance $= [ML^2T^{-2}]$

. Matches (s). Magnetic moment = Current $\times$

Area $= [AL^2]$

. Matches (q).

Dimensions of $\frac{1}{\sqrt{\mu_0 \epsilon_0}}$ are

▼

(a) $[L^2 T^{-2}]$

(b) $[L^{-2} T^2]$

(d) $[L^{-1} T]$

✓ Ans: (c)

Solution

The expression $\frac{1}{\sqrt{\mu_0 \epsilon_0}}$

is exactly the formula for the speed of light $c$

in a vacuum. Speed $= [LT^{-1}]$

💡 Cheat Point: Memorize EM constants! $c = 1/\sqrt{\mu_0\epsilon_0}$

. E/B = c. Both are velocity.

E, m, l and G denote energy, mass, angular momentum and gravitational constant. $\frac{El^2}{m^5G^2}$ has dimensions of:

▼

(a) angle(b) length(c) mass(d) time

✓ Ans: (a)

Solution

Substitute: $E = ML^2T^{-2}$

, $l = ML^2T^{-1}$

, $m = M$

, $G = M^{-1}L^3T^{-2}$

. Solving $\frac{(ML^2T^{-2})(M^2L^4T^{-2})}{M^5(M^{-2}L^6T^{-4})}$

yields $[M^0L^0T^0]$

. It is dimensionless, matching an angle.

Speed of light (c), G, and Planck’s constant (h) are fundamental. Dimensions of time should be

▼

(a) $G^{1/2} h^{1/2} c^{-5/2}$

(b) $G^{1/2} h^{1/2} c^{1/2}$

(d) $G^{1/2} h^{1/2} c^{1/2}$

✓ Ans: (a)

Solution

Assume $Time = c^x G^y h^z$

. Solving powers of M, L, T yields $x = -5/2, y = 1/2, z = 1/2$

In which pair do the quantities have different dimensions?

▼

(a) Planck’s constant and angular momentum
(b) Impulse and linear momentum
(c) Moment of inertia and moment of force
(d) Energy and torque

✓ Ans: (c)

Solution

Moment of inertia $= MR^2 = [ML^2]$

. Moment of force (Torque) $= F \times r = [ML^2T^{-2}]$

. They do not match.

Equation of state is $(P + \frac{a}{V^3})(V - b^2) = cT$ . Dimensions of a and b are:

▼

(a) $ML^8T^{-2}$

and $L^{3/2}$

(b) $ML^5T^{-2}$

and $L^3$

and $L^6$

(d) $ML^6T^{-2}$

and $L^{3/2}$

✓ Ans: (a)

Solution

By principle of homogeneity, $b^2$

must have dimensions of volume $V = L^3 \Rightarrow b = L^{3/2}$

. $\frac{a}{V^3}$

must match pressure $P = ML^{-1}T^{-2}$

. Therefore $a = ML^{-1}T^{-2} \times (L^3)^3 = ML^8T^{-2}$

h, c, and G are fundamental. Which combination has dimension of length?

▼

(a) $\sqrt{\frac{Gc}{h^{3/2}}}$

(b) $\frac{\sqrt{hG}}{c^{3/2}}$

(d) $\sqrt{\frac{hc}{G}}$

✓ Ans: (b)

Solution

Length $\propto h^a c^b G^c$

. Solving exponents gives $L = K \frac{\sqrt{hG}}{c^{3/2}}$

A length dimension can be formed out of c, G and $\frac{e^2}{4\pi\epsilon_0}$ as:

▼

(a) $\frac{1}{c^2}[G(\frac{e^2}{4\pi\epsilon_0})]^{1/2}$

(b) $c^2[G(\frac{e^2}{4\pi\epsilon_0})]^{1/2}$

(d) $\frac{1}{c}G(\frac{e^2}{4\pi\epsilon_0})$

✓ Ans: (a)

Solution

Note that $\frac{e^2}{4\pi\epsilon_0} = F \times r^2 = [ML^3T^{-2}]$

. Equating $L \propto c^x G^y (\frac{e^2}{4\pi\epsilon_0})^z$

leads to $x=-2, y=1/2, z=1/2$

$F = \alpha \beta \exp \left( -\frac{x^2}{\alpha k T} \right)$ . Dimension of $\beta$ is :

▼

(a) $M^2 L^2 T^{-2}$

(b) $M^2 L T^{-4}$

(d) $M L T^{-2}$

✓ Ans: (b)

Solution

The power in exponent $\frac{x^2}{\alpha k T}$

is dimensionless. $k T$

has dimensions of Energy ( $ML^2T^{-2}$

). So $\alpha = \frac{x^2}{kT} = \frac{L^2}{ML^2T^{-2}} = M^{-1}T^2$

. Now, $F = \alpha \beta \Rightarrow \beta = \frac{F}{\alpha} = \frac{MLT^{-2}}{M^{-1}T^2} = M^2LT^{-4}$

In $X = 5YZ^2$ , X is capacitance and Z is magnetic field. Dimensions of Y are:

▼

(a) $[M^{-2} L^{-2} T^6 A^3]$

(b) $[M^{-1} L^{-2} T^4 A^2]$

(d) $[M^{-2} L^0 T^{-1} A^{-2}]$

✓ Ans: (c)

Solution

$Y = \frac{X}{Z^2}$

. $X = [M^{-1}L^{-2}T^4A^2]$

, $Z = [MT^{-2}A^{-1}]$

. Then $Z^2 = [M^2T^{-4}A^{-2}]$

. Dividing them yields $Y = [M^{-3}L^{-2}T^8A^4]$

If speed (V), acceleration (A) and force (F) are fundamental, dimension of Young’s modulus is:

▼

(a) $V^{-2} A^2 T^{-2}$

(b) $V^{-4} A^2 F$

(d) $V^{-2} A^2 F^{-2}$

✓ Ans: (b)

Solution

Young’s Modulus $Y = \frac{F}{\text{Area}}$

. Area $= L^2$

. From $V = LT^{-1}$

and $A = LT^{-2}$

, we get $L = \frac{V^2}{A}$

. Thus, Area $= \frac{V^4}{A^2}$

. Substituting this back, $Y = F \times A^2 V^{-4}$

$F = A \cos Bx + C \sin Dt$ . Dimensional formula of $\frac{AD}{B}$ is

▼

(a) $M^2 L^2 T^{-3}$

(b) $M L T^{-2}$

(d) $M L^2 T^{-3}$

✓ Ans: (d)

Solution

Arguments of trig functions are dimensionless: $Bx = 1 \Rightarrow B = L^{-1}$

. $Dt = 1 \Rightarrow D = T^{-1}$

. F and A must match: $A = MLT^{-2}$

. Thus $\frac{AD}{B} = \frac{(MLT^{-2})(T^{-1})}{L^{-1}} = ML^2T^{-3}$

💡 Cheat Point: Cosines/Sines eat dimensions! Anything multiplying the variable inside ( $x$

or $t$

) is just the inverse of that variable’s dimension.

If momentum (P), area (A) and time (T) are fundamental, dimensional formula for coefficient of viscosity is

▼

(a) $[P A^{-1} T^0]$

(b) $[P A T^{-1}]$

(d) $[P A^{-1} T^{-1}]$

✓ Ans: (a)

Solution

Viscosity $\eta = [ML^{-1}T^{-1}]$

. $M = \frac{P}{V} = PL^{-1}T$

. $L = A^{1/2}$

. $\eta = (PA^{-1/2}T)(A^{-1/2})(T^{-1}) = PA^{-1}$

Speed of wave $v = \lambda^a g^b \rho^c$ . Values of a, b, c respectively are

▼

(a) $1/2, 0, 1/2$

(b) $1, -1, 0$

(d) $1/2, 1/2, 0$

✓ Ans: (d)

Solution

$[LT^{-1}] = [L]^a [LT^{-2}]^b [ML^{-3}]^c = M^c L^{a+b-3c} T^{-2b}$

. Comparing powers: $c=0$

, $-2b=-1 \Rightarrow b=1/2$

, $a+b=1 \Rightarrow a=1/2$

Experimental Skills & Instruments

Screw gauge: Two full turns cover 1 mm. Circular scale has 50 divisions. Zero error is -0.03 mm. Main scale reads 3 mm and circular scale reads 35. Diameter of the wire is

▼

(a) 3.38 mm(b) 3.32 mm
(c) 3.73 mm(d) 3.67 mm

✓ Ans: (a)

Solution

Pitch $= \frac{1\ mm}{2} = 0.5\ mm$

. Least count $= \frac{0.5}{50} = 0.01\ mm$

. Reading $= \text{Main Scale} + (\text{Circular Scale} \times LC) - \text{Zero Error}$

. Reading $= 3 + (35 \times 0.01) - (-0.03) = 3 + 0.35 + 0.03 = 3.38\ mm$

💡 Cheat Point: Negative zero error always ADDS to your final reading! Think of it like a clock running slightly slow—you must add time to get the true reading.

Frequently Asked Questions

Most searched questions on Units & Measurements for KVS NVS EMRS PGT Physics 2026 — answered in detail.

What is a parsec and what does it measure? +

A parsec is a unit of distance (not time) equal to approximately 3.086 × 10¹⁶ metres or about 3.26 light-years. It is derived from the parallax method: one parsec is the distance at which one astronomical unit (AU) subtends an angle of one arc-second. Despite containing “-sec,” parsec stands for Parallax Second — it uses arc-seconds as an angular measure, not as time. The suffix simply refers to the angle (arc-second) used in the parallax calculation. It is the standard unit for measuring distances to stars and galaxies outside our solar system.

How do you calculate percentage error in a derived quantity? What is the rule? +

The rule is: multiply each quantity’s percentage error by its power in the formula, then add all terms. For $P = \frac{a^3 b^2}{cd}$

: percentage error $= 3(\%a) + 2(\%b) + 1(\%c) + 1(\%d)$

. Key points — (1) Powers in numerator and denominator both contribute positively; errors always add, never subtract. (2) Fractional powers like ½ or ⅓ also become multipliers. (3) Constants like π or numerical factors contribute zero error. This rule is derived from taking the logarithm of the formula and differentiating — the absolute values ensure errors always add regardless of the sign of the power.

How many significant figures does 0.0003 have? What are the complete rules? +

0.0003 has only 1 significant figure. The complete rules: (1) All non-zero digits are always significant. (2) Leading zeros (before the first non-zero digit) are never significant — they only show decimal position. (3) Trapped zeros (between non-zero digits) are always significant — e.g., 23.023 → 5 sig figs. (4) Trailing zeros after a decimal point are significant — e.g., 9.980 → 4 sig figs. (5) In scientific notation $2.1 \times 10^{-3}$

, only the coefficient (2.1) counts — the power of 10 is ignored → 2 sig figs. For arithmetic: in addition/subtraction keep the least decimal places; in multiplication/division keep the least significant figures.

What are the dimensions of Gravitational constant G and how to derive them? +

From Newton’s law: $F = \frac{GM_1M_2}{r^2}$

, rearrange to $G = \frac{Fr^2}{M^2}$

. Substituting dimensions: $G = \frac{[MLT^{-2}][L^2]}{[M^2]} = [M^{-1}L^3T^{-2}]$

. This is one of the most tested dimensional formulas in PGT Physics. The negative power of M (i.e., M⁻¹) is the key identifier. SI value of G is $6.674 \times 10^{-11}\ Nm^2kg^{-2}$

, consistent with this dimension.

What does 1/√(μ₀ε₀) represent and what are its dimensions? +

$\frac{1}{\sqrt{\mu_0 \epsilon_0}}$

equals the speed of light c in vacuum (≈ 3 × 10⁸ m/s). This is a fundamental result from Maxwell’s electromagnetic equations. Its dimensions are $[LT^{-1}]$

— the dimension of velocity. Related facts: $\frac{E}{B} = c$

(ratio of electric to magnetic field in an EM wave) also has the same $[LT^{-1}]$

dimension. For MCQs: $[\mu_0\epsilon_0] = [L^{-2}T^2]$

, so $[1/\sqrt{\mu_0\epsilon_0}] = [LT^{-1}]$

How to handle negative zero error in a screw gauge? +

The formula is: True Reading = Observed Reading − Zero Error. For a negative zero error (e.g., −0.03 mm) — the gauge reads below zero when fully closed — subtracting a negative value means adding: True = Observed − (−0.03) = Observed + 0.03. For a positive zero error (+0.03 mm), you subtract: True = Observed − 0.03. Memory trick: a negative zero error means the instrument under-reports the size, so you must compensate by adding. Always note the sign carefully — it completely determines whether you add or subtract from the reading.

What is the percentage error formula for density of a cylinder (wire) vs a cube? +

For a cylinder/wire, density $\rho = \frac{M}{\pi r^2 L}$

: % error $= \%\Delta M + 2 \times \%\Delta r + \%\Delta L$

. The radius error is doubled because r is squared. For a cube, density $\rho = M/L^3$

: % error $= \%\Delta M + 3 \times \%\Delta L$

. The length error is tripled because L is cubed. Constants like π contribute zero error in both cases. This pair is among the most repeated question types in KVS, NVS and EMRS PGT Physics papers.

Which topics from Units & Measurements have highest weightage in KVS NVS EMRS PGT Physics 2026? +

Based on previous years’ KVS, NVS, and EMRS PGT Physics paper analysis, the highest-weightage subtopics are: (1) Dimensional Analysis with new fundamental unit systems — expressing quantities when F-v-T, P-A-T, E-v-F or h-c-G are taken as fundamental units. (2) Percentage error using power rule — especially density of cube/cylinder, pendulum g, and multi-variable formulas with fractional powers. (3) Significant figures — counting rules and arithmetic (subtraction and multiplication). (4) Screw gauge and Vernier caliper — pitch, least count, zero error correction. (5) Matching dimensional formulas — viscosity, surface tension, impulse, permeability, magnetic field. Astronomical units (parsec vs light-year vs AU) and wave equation dimensional consistency also appear regularly.

Why do moment of inertia and moment of force (torque) have different dimensions? +

Moment of inertia $I = mr^2$

has dimensions $[ML^2]$

— purely a geometric-mass property with no time dependence. Moment of force (Torque) $\tau = F \times r = ma \times r$

has dimensions $[ML^2T^{-2}]$

— it includes time because force involves acceleration ( $T^{-2}$

). They differ by $[T^{-2}]$

. This is a classic MCQ trap — both involve mass × length² but they are dimensionally different because one involves force and the other does not. For contrast: Energy and Torque both have dimensions $[ML^2T^{-2}]$

— they are dimensionally identical despite being physically different.

How to correctly find percentage error in g from a simple pendulum experiment? +

From $g = \frac{4\pi^2 L}{T^2}$

: % error in $g = \%\Delta L + 2 \times \%\Delta T$

. The most common mistake: using $\%\Delta T = \frac{\text{Least Count}}{\text{time for one oscillation}} \times 100$

. This is wrong. Correct method: $\%\Delta T = \frac{\text{Least Count of stopwatch}}{\text{Total time measured}} \times 100$

. The total time is what was directly measured (e.g., 30 s for 20 oscillations). Absolute error (1 s) applies to 30 s total → relative error = 1/30 = 3.33%, not 1/1.5. The factor of 2 multiplying $\%\Delta T$

comes from T being squared in the g formula.

Best of luck with your KVS, NVS, and EMRS PGT Physics preparation! Keep revising these cheat points daily.

Top 40 MCQs on Units & Measurements for KVS NVS EMRS PGT Physics Mains 2026 with Solutions

Units and Basic Concepts

Significant Figures & Error Analysis

Dimensional Analysis Masterclass

Experimental Skills & Instruments

Amit Patel

Leave a ReplyCancel Reply

About : TotheScience

Units and Basic Concepts

Significant Figures & Error Analysis

Dimensional Analysis Masterclass

Experimental Skills & Instruments

Amit Patel

Leave a ReplyCancel Reply

Related Posts

UP TGT Science Hand written Notes [Free]| Unit (i): Units, Measurements and Vectors Complete Notes 100% Free For UP TGT & PGT

Trending now

About : TotheScience
